The New GAL-PRO 8 Agricultural controller
กก
The Gal-Pro 8 is a new controller specially design for irrigation in
small open field plots and applications.
This controller is a stand alone, Battery or city power operated controller with the
following specifications:

-
This controller has 12 fixed outputs:
a. 8 irrigation valves
b. 1 master valve
c. 1 fertilizer pump output
d. 2 filter flushers
-
This controller has one special alarm output:
-
This controller has 8 fixed inputs:
a. 4 water meters
b. 1 fertilizer meter
c. 3 condition inputs.
-
The Gal pro has a unique HMI with special rotary switch that makes
operating this controller easy.
-
The Gal pro enables the operator to set up a program for each valve
independently or to schedule a series of programs that will operate
one after the other.
-
The Gal pro can be programmed to irrigate by time duration or by
water quantity.
-
The Gal pro can indicate and warn in case of water inflow and water
system damages.
-
This controller has some more advanced and unique features such as
co. valve, proportional fertilizing, condition inputs for special
operation and a lot more.
Tech Info:
a. Operate on two kind of battery voltage 6VDC or 12VDC according to the
operator needs.
b. The 12 outputs operate latch elements such as solenoids or latch
relay or 24VAC valves.
c. The 12 outputs latch electric pulses are as followed - 16VDC for
100ms pulse 1.8W.
d. The alarm output operates a 12vdc relay up to 150 mA.
